90° ANGLE DESIGN

Right Angle Pogo Pin Connector

Space-saving 90-degree design for compact PCB layouts and horizontal mounting applications. Perfect solution when vertical space is limited.

Request Quote View Gallery
Right Angle Pogo Pin Connector

Why Choose Right Angle Design?

Optimized for modern electronics where space efficiency is critical

Space Optimization

90-degree orientation saves valuable vertical PCB space, ideal for compact device designs

Low Profile Mounting

Horizontal contact points enable slim device profiles without compromising connection quality

Flexible Integration

Perfect for side-mounting configurations and multi-board assemblies with space constraints

Engineering Excellence

Our right angle pogo pin connectors are precision-engineered using advanced CNC machining to ensure perfect 90-degree geometry and consistent performance.

Precise Bend Angle

Exactly 90 degrees with tight tolerances for reliable PCB alignment

Optimized Contact Force

Calibrated spring mechanism ensures secure connection without PCB damage

Corrosion Resistant

Gold plating provides excellent conductivity and long-term reliability

CNC Machining Process

Technical Specifications

Mechanical Properties

  • Contact angle: 90° ± 2°
  • Spring force: 50-200gf (customizable)
  • Travel: 0.5mm – 3.0mm
  • Durability: 100,000+ cycles
  • Pitch options: 1.0mm – 5.0mm

Electrical Properties

  • Current rating: 1A – 10A
  • Contact resistance: <30mΩ
  • Insulation resistance: >100MΩ
  • Voltage rating: up to 36V DC
  • Operating temp: -40°C to 85°C
Rapidaccu Manufacturing

Rapidaccu Quality Commitment

With over 15 years of expertise, we deliver right angle pogo pin connectors that meet the highest industry standards.

Over 15 Years of Expertise in Pogo Pin and Connector Manufacturing

Certified Quality: ISO 9001, ISO 14001, ISO 45001, and IECQ QC080000

Exceptional Customer Support and Transparent Transactions

Frequently Asked Questions

What applications benefit from right angle pogo pins?

Right angle pogo pins are ideal for compact devices with height restrictions, side-mounted connectors, multi-board assemblies, and applications requiring horizontal PCB-to-PCB connections such as slim smartphones, wearables, and IoT devices.

How accurate is the 90-degree angle?

Our CNC machining processes ensure the bend angle is precisely 90 degrees with a tolerance of ±2 degrees. This accuracy is critical for proper PCB alignment and reliable electrical contact in your assembly.

Can you customize the pitch spacing?

Yes, we offer customizable pitch spacing from 1.0mm to 5.0mm to match your PCB layout requirements. Common pitches include 1.27mm, 2.0mm, 2.54mm, and custom options based on your design specifications.

What mounting styles are available?

We offer SMT (surface mount), through-hole, and solder cup mounting styles for right angle pogo pins. The choice depends on your assembly process, PCB design, and mechanical requirements. Our team can recommend the optimal solution.

What plating options do you provide?

We offer gold plating (most common for superior conductivity), nickel plating, and tin plating. Gold plating is recommended for high-reliability applications requiring low contact resistance and excellent corrosion protection.

Do you provide technical design support?

Yes, our engineering team offers comprehensive technical support including design consultation, PCB layout recommendations, prototype development, and testing assistance to ensure optimal connector performance in your application.
